Ignition Coil 12690761/H6T15771BC UF912
IGNX No: STIC4125
OE No.:
12690761
H6T15771BC
SMP :
Inquiry Now >>
UF-912 (UF912)
Product Detail
| ST NO. | Brand | OEM No. | Model(s) & Years | PINS | MODULE |
| STIC4125 | CADILLAC | 12690761 H6T15771BC |
CADILLAC CT4 2.7T (2020) | 4 PINS | WITH |
| CHEVROLET | 12690761 H6T15771BC |
CHEVROLET SILVERADO 1500 2.7T (2019-2022) | 4 PINS | WITH | |
| GMC | 12690761 H6T15771BC |
GMC SIERRA 1500 2.7T (2019-2022) | 4 PINS | WITH |
This Cadillac / Chevrolet / GMC ignition coil is supplied for the listed OE numbers 12690761 and H6T15771BC. It features a 4 pins connector and with-module configuration, making the connector layout, module structure, housing design, and mounting arrangement useful points to review during replacement-product selection.
When comparing the product with the original coil, buyers can review the listed OE number together with connector orientation, terminal position, plug direction, housing profile, mounting point, and overall dimensions. Checking several structural details together provides a more complete reference than relying only on exterior appearance.
Connector and Module Details to Check
Listed OE Numbers
Check the applicable listed OE number against the original part during sample review, quotation, catalog preparation, or order confirmation. The OE reference can be reviewed together with the physical structure of the coil.
4 Pins Connector
The 4 pins connector is an important visible matching feature. Terminal layout, connector shape, locking position, plug direction, and installation orientation can be compared with the original ignition coil.
With Module Configuration
This ignition coil is listed as with module. Module configuration can be reviewed together with the connector and housing structure when confirming the required replacement design.
Electrical Construction and Inspection Focus
Ignition coil operation is related to the primary and secondary windings, internal insulation, terminals, electrical connections, and control-related components within the coil assembly. These areas can be considered during product evaluation together with connector fit, housing condition, and installation dimensions.
Engine heat, temperature changes, vibration, and repeated electrical loading are common operating conditions for ignition components. Depending on the buyer's inspection requirements, evaluation may include connector and terminal condition, housing and assembly condition, insulation-related characteristics, and relevant electrical measurements.
Sample and Batch Order Reference
For sample evaluation, buyers can compare the replacement coil with the original part for the listed OE number, 4 pins connector, with-module structure, connector orientation, housing profile, and mounting details. Original coil photos or connector close-ups can also be used as additional reference when required.
For regular purchasing, the confirmed sample specification can be used as a reference for subsequent order communication. Product version, packaging method, label information, order quantity, and other project-specific requirements can be reviewed according to the buyer's purchasing plan.
