Ignition Coil SMW250131/93363483 UF503
IGNX No: STIC2204
OE No.:
SMW250131
93363483
25182496
96253555
SMP :
Inquiry Now >>
UF-503 (UF503)
Product Detail
| ST NO. | Brand | OEM No. | Model(s) & Years | PINS | MODULE |
| STIC2204 | CHERY | SMW250131 | CHERY TIGO (2005-2008) | 3 PINS | WITHOUT |
| CHEVROLET | 93363483 25182496 |
CHEVROLET MATIZ 1.0L (2005-/) CHEVROLET KALOS 1.2L / 1.4L (2005-/) CHEVROLET LACETTI 1.8L (2005-/) CHEVROLET NUBIRA 1.8L (2005-/) CHEVROLET REZZO 1.6L / 2.0L (2005-/) CHEVROLET EVANDA 2.0L (2005-/) CHEVROLET AVEO 1.2L / 1.4L / 1.5L (2006-/) CHEVROLET EPICA 2.0L (2005-2006) CHEVROLET CAPTIVA 2.4L (2006-/) CHEVROLET OPTRA 2.0L (1999-2003) CHEVROLET SPARK 1.0L / 1.2L (2005-/) CHEVROLET VIVANT 2.0L (2000-/) CHEVROLET CRUZE 1.6L (2009-/) CHEVROLET LANOS 1.5L (2005-/) |
3 PINS | WITHOUT | |
| DAEWOO | 96253555 | DAEWOO LANOS 1.4L / 1.5L (1997-/) DAEWOO NUBIRA 1.6L / 1.8L / 2.0L (1997-2003) DAEWOO KONDOR 2.0L / 2.2L (1997-2004) DAEWOO MATIZ 1.0L (2003-/) DAEWOO REZZO 1.6L / 1.8L / 2.0L (2000-2004) DAEWOO KALOS 1.2L / 1.4L/ 1.5L (2002-2004) DAEWOO EVANDA 2.0L (2002-/) DAEWOO LACETTI 1.8L / 2.0L (1997-2004) DAEWOO MAGNUS 2.0L (1999-/) |
3 PINS | WITHOUT |
This Chery / Chevrolet / Daewoo ignition coil is supplied for the listed OE numbers SMW250131, 93363483, 25182496, and 96253555. It uses a 3 pins connector and without-module configuration, so the electrical interface, housing structure, mounting arrangement, and overall coil design are useful points to review during product confirmation.
Because several OE references are listed for this product, buyers can compare the applicable number together with connector orientation, terminal position, plug direction, housing profile, mounting details, and overall dimensions of the original coil. Reviewing these points together can provide a clearer basis for matching than relying on one identifier or exterior appearance alone.
OE Reference and Physical Matching Check
Listed OE Numbers
Confirm the applicable listed OE number against the original component during sample review, catalog preparation, quotation, or order confirmation. OE information can be checked together with the physical coil design.
3 Pins Connector
The 3 pins connector is an important visible matching point. Connector shape, terminal layout, locking position, plug direction, and installation orientation can be compared with the original ignition coil.
Without Module Structure
This ignition coil is listed as without module. Module status can be reviewed together with connector layout, housing design, and mounting structure when confirming the required replacement configuration.
Electrical Construction and Working Environment
Ignition coil condition is related to the primary and secondary windings, internal insulation, terminals, and electrical connections. During product evaluation, these areas can be considered together with connector fit, housing condition, mounting dimensions, and general assembly condition.
Engine vibration, repeated temperature changes, and electrical loading are common conditions around ignition components. Depending on the inspection requirements, checking may include terminal contact, connector condition, housing integrity, insulation-related characteristics, and relevant electrical measurements. Spark plug condition and plug gap can also be considered when reviewing the surrounding ignition system.
Sample and Batch Specification Review
During sample evaluation, the replacement coil can be compared with the original part for the applicable OE number, 3 pins connector, without-module structure, connector orientation, housing profile, and mounting details. Original coil photos or connector close-ups can provide additional reference when further visual confirmation is required.
For repeat or batch purchasing, the approved sample can be retained as a reference for product structure, connector configuration, visible assembly details, labeling, and packaging requirements. Any project-specific specifications can then be reviewed before subsequent order arrangements.
