Ignition Coil BR3Z12029A/BR3E12A375AA UF622
IGNX No: STIC4024
OE No.:
BR3Z12029A
BR3E12A375AA
SMP :
Inquiry Now >>
UF-622 (UF622)
Product Detail
| ST NO. | Brand | OEM No. | Model(s) & Years | PINS | MODULE |
| STIC4024 | FORD | BR3Z12029A BR3E12A375AA |
FORD F-150 5.0L V8 (2011) FORD MUSTANG 5.0L V8 (2011-2014) |
2 PINS | WITHOUT |
This Ford ignition coil is supplied for the listed OE numbers BR3Z12029A and BR3E12A375AA. It uses a 2 pins connector and without-module configuration, so connector layout, housing profile, mounting position, and overall coil structure are useful points to review when selecting a replacement product.
During product comparison, buyers can check the listed OE number together with connector orientation, terminal position, plug direction, housing shape, mounting details, and overall dimensions of the original coil. Reviewing several physical details together provides more reference than identifying the product only by exterior appearance.
Key Structure Details to Review
Listed OE Numbers
Check BR3Z12029A or BR3E12A375AA against the original part during sample review, quotation, catalog preparation, or order confirmation. The OE reference can be considered together with the physical coil structure.
2 Pins Connector
The 2 pins connector is one of the main visible matching points. Connector shape, terminal arrangement, locking position, plug direction, and installation orientation can be compared with the original ignition coil.
Without Module Configuration
This ignition coil is listed as without module. Module status can be reviewed together with connector and housing details when confirming the required replacement structure.
Winding, Insulation and Electrical Condition
Ignition coil operation is related to the primary and secondary windings, internal insulation, terminals, and electrical connections. During product evaluation, these areas can be considered together with connector fit, housing condition, mounting dimensions, and overall assembly condition.
Engine heat, temperature changes, vibration, and repeated electrical loading are common operating conditions around ignition components. Depending on the buyer's inspection requirements, evaluation may include connector and terminal condition, housing condition, insulation-related characteristics, and relevant electrical measurements.
Sample and Order Specification Review
During sample evaluation, the replacement coil can be compared with the original part for the listed OE number, 2 pins connector, without-module structure, connector orientation, housing profile, and mounting details. Original coil photos or connector close-ups can also provide additional reference when further comparison is required.
For regular purchasing, the reviewed sample and confirmed product structure can serve as a reference for later order communication. Packaging method, label information, required quantity, and other project-specific details can be reviewed according to the buyer's purchasing requirements.
