Replacement Ignition Coil JL3E12A366AA UF825
IGNX No: STIC4013
OE No.:
JL3E12A366AA
UF825
SMP :
Inquiry Now >>
UF-825 (UF825)
Product Detail
| ST NO. | Brand | OEM No. | Model(s) & Years | PINS | MODULE |
| STIC4013 | FORD | JL3E12A366AA UF825 |
FORD F-150 3.3L (2018-2022) FORD TRANSIT-250 3.5L (2020-2022) FORD TRANSIT-350 3.5L (2020-2022) FORD TRANSIT-350 HD 3.5L (2020-2022) FORD EXPLORER 3.5L (2020-2022) |
2 PINS | WITHOUT |
This Ford ignition coil is supplied for the listed OE number JL3E12A366AA and UF852. It uses a 2 pins connector and without-module configuration, so connector layout, housing profile, mounting arrangement, and overall coil structure are useful points to review when selecting a replacement product.
During product comparison, buyers can review the OE number together with connector orientation, terminal position, plug direction, housing shape, mounting details, and overall dimensions of the original coil. Checking several structural details together provides a clearer reference than identifying the product only by exterior appearance.
Key Structure Details to Review
Listed OE Number
Check JL3E12A366AA and UF852. against the original part during sample review, quotation, catalog preparation, or order confirmation. The OE reference can be considered together with the physical structure of the coil.
2 Pins Connector
The 2 pins connector is an important visible matching feature. Connector shape, terminal arrangement, locking position, plug direction, and installation orientation can be compared with the original ignition coil.
Without Module Configuration
This ignition coil is listed as without module. Module status can be reviewed together with connector and housing details when confirming the required replacement structure.
Electrical Construction and Condition Checks
Ignition coil operation is related to the condition of the primary and secondary windings, internal insulation, terminals, and electrical connections. During product evaluation, these areas can be considered together with connector fit, housing condition, mounting dimensions, and general assembly condition.
Engine heat, temperature changes, vibration, and repeated electrical loading are common operating conditions around ignition components. Depending on the buyer's inspection requirements, evaluation may include connector and terminal condition, housing condition, insulation-related characteristics, and relevant electrical measurements.
Sample and Product Specification Review
During sample evaluation, the replacement coil can be compared with the original part for the listed OE number, 2 pins connector, without-module structure, connector orientation, housing profile, and mounting details. Original coil photos or connector close-ups can provide additional reference when further comparison is required.
For regular purchasing, the reviewed sample and confirmed product structure can serve as a reference for later communication. Packaging method, label information, required quantity, and other project-specific details can be reviewed according to the buyer's purchasing requirements.
