Ignition Coil 96476979/55570160 UF850
IGNX No: STIC4104
OE No.:
96476979
55570160
25186686
24107494
CE8766218B1
SMP :
Inquiry Now >>
UF-850 (UF850)
Product Detail
| ST NO. | Brand | OEM No. | Model(s) & Years | PINS | MODULE |
| STIC4104 | CHEVROLET | 96476979 55570160 25186686 24107494 CE8766218B1 |
CHEVROLET AVEO 1.4L (2008-/) CHEVROLET CRUZE 1.6L / 1.8L (2009-/) CHEVROLET ORLANDO 1.8L (2011-/) |
7 PINS | WITHOUT |
This Chevrolet ignition coil is supplied for the listed OE numbers 96476979, 55570160, 25186686, 24107494, and CE8766218B1. It uses a 7 pins connector and without-module configuration, so connector layout, housing profile, mounting arrangement, and overall coil structure are important points to review when confirming the required replacement product.
Because several OE references are listed for this coil, buyers can compare the applicable number together with connector orientation, pin arrangement, locking position, plug direction, housing shape, and mounting details. Reviewing these physical characteristics together provides a clearer basis for identification than relying on the OE number or product appearance alone.
7 Pins Interface and Structure Check
Listed OE References
Confirm the applicable listed OE number against the original component during sample review, quotation, catalog preparation, or order confirmation. The OE reference can be checked together with the physical coil design.
7 Pins Connector
The 7 pins connector is a key matching feature. Pin arrangement, connector keying, locking structure, plug direction, and connector orientation can be compared with the original ignition coil before product approval.
Without Module Structure
This ignition coil is listed as without module. Module status should be reviewed together with the connector configuration, housing design, and mounting structure when confirming the required product version.
Electrical and Insulation Inspection Focus
Ignition coil operation is related to the primary and secondary windings, internal insulation, terminals, and electrical connections. During product evaluation, these areas can be considered together with connector fit, housing condition, mounting dimensions, and visible assembly condition.
Engine heat, repeated temperature changes, vibration, and electrical loading are common working conditions around ignition components. Depending on the inspection requirements, checking may include terminal contact, connector condition, housing integrity, insulation-related characteristics, and relevant electrical measurements.
Sample and Incoming Inspection Reference
For sample approval, the supplied coil can be compared with the original part for the applicable OE number, 7 pins connector, without-module structure, connector orientation, housing profile, and mounting details. Original-part photos or connector close-ups can also be retained as visual references when additional confirmation is needed.
For repeat or batch purchasing, the approved sample can serve as a reference during incoming inspection for connector configuration, visible assembly details, labeling, and packaging. Any additional order-specific requirements can be confirmed according to the actual purchasing project.
