Ignition Coil 56029129AA/56029129AB UF504
IGNX No: STIC4805
OE No.:
56029129AA
56029129AB
56029129AF
68060346AA
SMP :
Inquiry Now >>
UF-504 (UF504)
Product Detail
| ST NO. | Brand | OEM No. | Model(s) & Years | PINS | MODULE |
| STIC4805 | CHRYSLER | 56029129AA 56029129AB 56029129AF 68060346AA |
CHRYSLER 300 5.7L / 6.1L (2004-2012) | 3 PINS | WITHOUT |
| DODGE | 56029129AA 56029129AB 56029129AF 68060346AA |
DODGE CHARGER 5.7L / 6.1L (2005-2010) DODGE DURANGO 5.7L (2003-2010) DODGE RAM 1500 5.7L (2001-2008) DODGE RAM 2500 5.7L (2002-2009) DODGE RAM 4000 5.7L (2005-2012) |
3 PINS | WITHOUT | |
| JEEP | 56029129AA 56029129AB 56029129AF 68060346AA |
JEEP GRAND CHEROKEE 5.7L / 6.1L / 6.4L (2005-2016) JEEP COMMANDER 5.7L (2005-2010) |
3 PINS | WITHOUT |
This Chrysler / Dodge / Jeep ignition coil is supplied for the listed OE numbers 56029129AA, 56029129AB, 56029129AF, and 68060346AA. It uses a 3 pins connector and without-module configuration for replacement applications requiring this type of ignition coil structure.
During product confirmation, buyers can compare the listed OE number with the connector form, terminal position, plug direction, housing profile, mounting points, and overall dimensions of the original coil. Reviewing several matching details together is useful because coils with similar exterior shapes may still differ in connection or installation structure.
Matching Details to Check Before Ordering
Listed OE Numbers
Check the applicable listed OE number against the original part during quotation, sample review, catalog preparation, or order confirmation. The number can be reviewed together with the physical coil structure.
3 Pins Connector
The 3 pins connector is one of the visible matching points. Connector shape, terminal layout, locking position, plug direction, and installation angle can be compared with the original ignition coil.
Without Module Structure
This ignition coil is listed as without module. Module status can be checked together with connector and housing details when comparing products for replacement or aftermarket supply.
Electrical Construction and Inspection Focus
Ignition coil operation is related to the condition of the primary and secondary windings, internal insulation, terminals, and electrical connections. During product evaluation, these areas can be considered together with connector fit, housing condition, and installation dimensions.
Heat, temperature changes, vibration, and repeated electrical loading are common operating conditions around the engine. Depending on the buyer's inspection requirements, product checking may include housing condition, terminal contact, connector fit, insulation-related characteristics, and relevant electrical measurements.
Order Confirmation & Supply Information
When requesting a quotation, buyers can provide the listed OE number, required quantity, packaging preference, label information, and expected delivery schedule. If further matching is needed, original coil photos, connector close-ups, or housing images can also be provided for reference.
For sample checking or regular purchasing, the required product structure, packaging method, labeling details, and other order information can be discussed with IGNX according to the specific purchasing requirements.
